100mm T Plate

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

Metal corner plate for strengthening corners. Pre-drilled fixing holes for use with countersunk screws.
Bright Zinc Plated (BZP) for corrosion resistance.

Thickness: 2.0mm
Width: 16mm
Length: 100mm x 100mm
Fixing Holes: 6.0mm (x6)

Galvanised Truss Clip for constructing timber to timber framework. Precision formed and engineered for fast installation and maximum loads.

- Suitable for securing 47mm wide timber
- Overall Width - 105mm (including fixing wings)
- Length - 100mm

Install using 3.75 x 30mm square twist nails
6 nail holes / truss clip
1 kg square twist nails installs approx. 58 truss clips

Simpson Strong-Tie NP15/80/140 nail plates can be used in various applications, in particular for jointing or the connection of wood elements in the same plane.

Thickness: 1.5mm
Width: 40mm
Length: 120mm
Fixing Holes: 5.0mm (x9)

- Machined from 47 x 75mm, finished size approx. 45 x 70mm
- Smooth regularised finish
- Grade C16 / C24 - mixed
- Good quality, slow grown softwood
- Pressure treated green
