450mm Galvanised Medium T- Hinge - Single

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

A heavy steel washer, for general use with bolts and threaded bar (studding).
BZP (Bright Zinc Plate) finish.

Dimensions: 2mm x 28mm Diameter
13mm Bolt Hole: To suit M12 thread

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 10mm
Anchor Length - 150mm
Washer Size - 12mm (M12)
Min Hole Depth - 70mm
Min Over Drill Depth - 20mm
Min. Embed Depth - 50mm
Max. Fixture Thickness - 100mm
Drill Bit Dia. for clearance - 12mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 17mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 60Nm

A light duty fixing for jobs where speed of installation is important.
Hammer fixings work in a similar way to screws and plugs, the hammer fixing screw has a special thread that can be hammered into the plug and loosened / screwed out if required.

Installation:
Pre-drill a 10mm pilot hole through the item that you're fixing and into the masonry or brickwork. Lightly tap the fixing through the pilot hole with a hammer until the plug is flush. EG. if you're fixing a timber wall plate, the plug fits inside the timber as well as the wall. Once the plug is flush with the timber, hit the head of the screw harder to drive it into the plastic sleeve until tight.

Minimum fixing depth: 45mm

General purpose, pressure treated, sawn finish timber. Mainly used for agricultural post & rail fencing (also known as motorway fencing) and feather-edge fencing.

- Dimensions: 38 x 88mm x 3.0m
- Sawn Finish
- Homegrown Softwood, locally produced in the UK
- Pressure Treated - Green

General purpose, pressure treated, sawn finish timber. Mainly used as fence posts but could have many other uses.

- Dimensions: 75 x 75mm x 2.1m
- Homegrown Softwood, locally produced in the UK
- Sawn & incised finish
- Fully incised surface for improved treatment penetration
- UC4 Pressure Treatment - Green
