50mm Fence Panel U-Clip

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 75mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 35mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm

General purpose, pressure treated, sawn finish timber. Mainly used as fence posts but could have many other uses.

- Dimensions: 100 x 100mm x 2.7m
- Homegrown Softwood, locally produced in the UK
- Fully incised surface for improved treatment penetration
- UC4 Pressure Treatment - Green

Hardwood Anti-rattle Panel Wedge; designed to stop fence panels rattling when fitted into slotted concrete posts. To ensure a tight fit, tap the wedge into the gap between the fence panel and the post slot. Fix the wedge in position by driving a screw into the fence panel through the pre-drilled hole. For best results fit 4 wedges per panel, this may vary depending on your specific fence panel and concrete slot dimensions. This wedge is pressure treated brown.
Screws sold separately.

- Hardwood Wedge
- Pre-drilled for 4.0mm screw
- Pressure Treated (brown)

Wedge Dimensions:
- Height: 52mm
- Width: 42mm
- Depth: (approx.)17mm tapering to 7mm

A heavy steel washer, for general use with bolts and threaded bar (studding).
BZP (Bright Zinc Plate) finish.

Dimensions: 2mm x 24mm Diameter
11mm Bolt Hole: To suit M10 thread
