M8 Form C Washer

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

Carriage Bolt; cup square hex, 20mm mushroom head, BZP finish (Bright Zinc Plate). Designed for bolting through timber.

Square hex refers to the square section attached to the mushroom head, this sinks into timber and stops the bolt from spinning when the nut is tightened.

Supplied with one standard hex nut, washers sold separately.

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

- Premium 5th grade Redwood Softwood Decking
- Machined from 38 x 125mm timber to approx. 33 x 120mm
- Dual-sided groove pattern
- Pressure treated green with 15-year warranty
- DeckMark accredited, ideal for easy installation with maximum joist centres of 600mm.

Carriage Bolt; cup square hex, 20mm mushroom head, BZP finish (Bright Zinc Plate). Designed for bolting through timber.

Square hex refers to the square section attached to the mushroom head, this sinks into timber and stops the bolt from spinning when the nut is tightened.

Supplied with one standard hex nut, washers sold separately.

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 75mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 35mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm
