Oval Padbolt - Black

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

- Machined from 47 x 75mm, finished size approx. 45 x 70mm
- Smooth regularised finish
- Grade C16 / C24 - mixed
- Good quality, slow grown softwood
- Pressure treated green

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 130mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 90mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm

Premium Quality Softwood Decking

- Profile machined from 32 x 125mm timber, finished size approx. 28 x 120mm
- Dual sided pattern - smooth / grooved
- Machined from 5th grade Redwood, quality slow-grown material
- Pressure treated green, 15 year Treated-Right Warranty, details in Downloads tab below
- This decking product is DeckMark accredited
- Maximum joist centres - 450mm
- We have stocked this decking profile since 2010 due to popularity

General purpose, pressure treated, sawn finish timber. Mainly used as fence posts but could have many other uses.

- Dimensions: 75 x 75mm x 1.8m
- Sawn Finish
- Homegrown Softwood, locally produced in the UK
- Pressure Treated - Green

Carriage Bolt; cup square hex, 30mm mushroom head, BZP finish (Bright Zinc Plate). Designed for bolting through timber.

Square hex refers to the square section attached to the mushroom head, this sinks into timber and stops the bolt from spinning when the nut is tightened.

Supplied with one standard hex nut, washers sold separately.
